WS2812B WS2811 WS2815 WS2813 RGBIC LED Strip WS2812 30/60/144Pixels/Leds/m Individually Addressable Smart Tape Light DC5V/12V
247.80৳ – 3,353.00৳
| Emitting Color |
WS2811 ,WS2812B ,WS2813 ,WS2815 |
|---|---|
| Color |
Black PCB ,White PCB |
| Wattage |
1M 144 IP30 ,1M 144 IP65 ,1M 144 IP67 ,1M 30 IP30 ,1M 30 IP65 ,1M 30 IP67 ,1M 60 IP30 ,1M 60 IP65 ,1M 60 IP67 ,2M 144 IP30 ,2M 144 IP65 ,2M 144 IP67 ,2M 30 IP30 ,2M 60 IP30 ,3M 144 IP30 ,3M 144 IP67 ,3M 30 IP30 ,3M 60 IP30 ,4M 30 IP30 ,4M 60 IP30 ,5M 30 IP30 ,5M 30 IP65 ,5M 30 IP67 ,5M 60 IP30 ,5M 60 IP65 ,5M 60 IP67 |
♦ Disclaimer: AliMarket একটি ক্রস বর্ডার শপিং সার্ভিস প্রোভাইডার। আমাদের মূল লক্ষ্য বর্ডার বাধা পেরিয়ে আপনাকে কাঙ্ক্ষিত পণ্য এনে দেওয়া। AliMarket এ প্রদর্শিত প্রোডাক্ট বিভিন্ন থার্ড পার্টি শপিং ওয়েবসাইট থেকে সংগৃহীত। অর্থাৎ AliMarket সরাসরি কোন পণ্যের সেলার বা ম্যানুফ্যাকচারার নয়। তাই AliMarket কোনো প্রাসঙ্গিক, জামানত বা যৌথ দায় নিতে বাধ্য নয়। তবে গ্রাহক স্বার্থ রক্ষার্থে শপিং ওয়েবসাইটের রিফান্ড পলিসি অনুসারে AliMarket বিফর এবং আফটার সেলস সার্ভিস দেয়।
- Luminous Flux: 60-249
- Hign-concerned Chemical: None
- Is Smart Device: YES
- Power Generation: SWITCH
- Model Number: WS2812B/WS2811/WS2813/WS2815
- LED Chip Model: SMD5050
- Average Life (hrs): More than 50000 hours
- Certification: CCC,ce,FCC,ROHS
- Power Source: DC
- Origin: Mainland China
- Strip type: Flat 3-wire
- Power Consumption (W/m): 11.52W/m
- Occasion: LIVING ROOM
- Specifications (light beads / m): 30/60/144
- Item Type: Strip
- Brand Name: TNALANT
- Voltage: 5V/12V
- LEDs Number/M: 30/60/144Leds/m
- LED Chip Brand: Epistar
- Waterproof: Yes
- Color Temp(K): K
WS2812B RGB LED Strip WS2811 WS2815 WS2813 WS2812 Individually Addressable 30/60/144pixels/Leds/M Tape Light IP30/65/67 DC5V/12V
Pay attention：
1. Led strip welded by 0.5m is very normal in an electronic product,not a quality problem.if you mind this, do not place order！
2. IP30: Non- Waterproof
IP65: Waterproof in Silicon Coating
IP67: Waterproof in SiliconTube
3.If the order no more than $5 ,no tracking number !!
this link is not include power supply and led controller,please know it
WS2811 LED Strip:
(1) Working Voltage: DC 12V
(2) LED Source: SMD 5050 RGB
(3) LED Chip: Epistar
(4) LED QTY: 30/60 LED / M
(5) IC QTY: 10/20M
(6) Power: 9/18W /M
(7) Grey scale: 256 / Color
(8) Cutability: 3 led / cutting (Similar WS2811, 1 ic control 3 LED)
(9) Beam Angle: 120 °
(10) Color Mode: 133Pattern & 100 Speeds
(11) IP Grade: ip30 non -waterproof / ip67 waterproof
(12) Dimension: 5000 x 10 x 2.4mm
(13) Packaging: 5m/roll 12v WS2811 RGB Strip + 3Pin Connector
(14) Warranty: 2Years
Input Voltage: DC5V
Power: 30Leds/m—-9Watt/meter
60Leds/m—-18Watt/meter
144Leds/m—-43.2Watt/meter
LED Resource: WS2812B Led(5050 SMD RGB LED With Built-in Improved Version Of WS2811 IC)
LED: Each Led is Separately Controlled
IC Type: Improved Version WS2812 IC(Built Inside The 5050SMD RGB LED)
Of IC: 1 IC Drives 1 Led Chip
Pixels: 30/60/144/Meters
Pitch: 16.6mm(1000/64)
Grey Scale: 256
Bits/Color: 8-Bits/Color
FPC Width: 30Leds/m—-10mm
60Leds/m—-10mm
144Leds/m—-12mm
FPC color: Black/White
Protection Rate: IP30/ IP65 /IP67
Colors: Full Color RGB, Dream Color Changing
Cuttable: Every LED is Cuttable
Package:In Anti-Static Bag,IP30 IP65 With 3M Adhensive Tape On The Back(IP67 Without 3M Adhensive)
WS2813 LED Strip:
Input Voltage: DC5V
Power: 30 Leds/M — 9 Watt/Meter / 60 Leds/M — 18 Watt/Meter / 144 Leds/M — 43.2 Watt/Meter
LED Resource: WS2813 led (5050 SMD RGB LED with built-in improved version of ws2811 ic)
LED: Each LED is separately controlled
IC Type: Improved version ws2813 IC(built inside the 5050 smd rgb led)
Of IC: (1 IC Drives 1 led chip)
Pixels: 30Leds/60Leds/144Leds/meter
Pitch: 16.6mm(1000/64)
Grey Scale: 256
Colors: Full color RGB, dream color changing
Bits/Color: 8-Bits/Color
FPC Color: BLACK / White
FPC Width: 30 Leds/M — 10 MM / 60 Leds/M — 10 MM / 144 Leds/M — 12 MM
Protection Rate: IP30 Non-Waterproof / IP65 Waterproof in Silicon Coating / IP67 Waterproof in Silicon Tube
Cuttable: Every LED is cuttable
Package: In anti-static bag, IP30 IP65 with 3M adhensive tape on the back (IP67 without 3M adhensive), each strip with one free male connector for connector
Working Temperature: -40 – 70 °C
Storage Temperature: -50 – 80 °C
Source Life: 50,000 hours
Connector: 4PIN connector terminal pair (Red: 5V power, Green: Date line, Blue: standby date line, Black: GND)
Recommand controllers: T-1000s,T-8000A;T-100K;T-200K;T-300K
WS2815 LED Strip:
Input voltage:………….DC12V;
Power:…………………..30leds/m—-9watt/meter
…………………..60leds/m—-18watt/meter
…………………..144leds/m—-34watt/meter
LED resource:………..WS2815 led(5050 SMD RGB LED with built-in improved version of ws2811 ic)
LED: ……………Each LED is separately controlled
IC Type: ………………..Improved Version WS2815 IC(built inside the 5050 smd rgb led)
of IC: ………………(1 IC drives 1 led chip);
Pixels: ………30/60/144/meter;
Pitch: ……………………16.6mm(1000/64);
Grey scale: ……………256;
Bits/color: ……………..8-bits/color;
FPC Width: :…………..30leds/m—-10mm
…………………..60leds/m—-10mm
………………….144leds/m—-12mm
FPC color: ………White/Black PCB
Protection rate ……IP30/ IP65 /IP67
Colors: …………………..Full color RGB, dream color changing;
Cuttable:…………………every LED is cuttable;
Package: ……………….in anti-static bag,IP30 IP65 with 3M adhensive tape on the back(IP67 without 3M adhensive)
Working temperature……………-40 ~ 70 °C
Storage temperature……………-50 ~ 80 °C
Source life ……………50,000 hours
Connector ……………4PIN Connector terminal pair
(Red: 12V power , Green: Date line, Blue: standby date line,Black: GND)
