STC-3008 3018 3028 Dual Digital Temperature Controller Hygrometer C/F Thermostat Two Relay Output AC 110V 220V DC 12V 24V 10A
434.00৳ – 758.80৳
| Color |
STC-3008 AC 110-220V ,STC-3008 DC 12V ,STC-3008 DC 24V ,STC-3018 AC 110-220V ,STC-3018 DC 12V ,STC-3018 DC 24V ,STC-3028 AC 110-220V ,STC-3028 DC 12V ,STC-3028 DC 24V |
|---|
♦ Disclaimer: AliMarket একটি ক্রস বর্ডার শপিং সার্ভিস প্রোভাইডার। আমাদের মূল লক্ষ্য বর্ডার বাধা পেরিয়ে আপনাকে কাঙ্ক্ষিত পণ্য এনে দেওয়া। AliMarket এ প্রদর্শিত প্রোডাক্ট বিভিন্ন থার্ড পার্টি শপিং ওয়েবসাইট থেকে সংগৃহীত। অর্থাৎ AliMarket সরাসরি কোন পণ্যের সেলার বা ম্যানুফ্যাকচারার নয়। তাই AliMarket কোনো প্রাসঙ্গিক, জামানত বা যৌথ দায় নিতে বাধ্য নয়। তবে গ্রাহক স্বার্থ রক্ষার্থে শপিং ওয়েবসাইটের রিফান্ড পলিসি অনুসারে AliMarket বিফর এবং আফটার সেলস সার্ভিস দেয়।
- Measure Type: K
- Screw: M12*1.5
- Cable Length: 1M
- Type: K
- Theory: Temperature Controller
- Display Type: DIGITAL
- Power Type: Charger
- Certification: none
- Model Number: STC-3008/3018/3028 Temperature hygrometer controller
- Display Size: 1.9 Inches & Under
- Origin: Mainland China
- Max Measuring Temperature: 100°C – 119°C
- Style: Standing and Wall Hanging
- Brand Name: ERIKOLE
- Usage: Industrial
- Is Smart Device: no
STC-3008
|
Code |
Function |
Set Range |
Default |
|
P0 |
Compressor 1 delay time |
0-60min |
0min |
|
P1 |
Compressor 2 delay time |
0-60min |
0min |
|
P2 |
High temperature alarm value |
55-120 ° C |
120 ° C |
|
P3 |
Low temperature alarm value |
55-120 ° C |
-55 ° C |
-
Automatic conversion of refrigeration and heating mode
-
2.Control mode of return difference;Temperature display resolution 0.1
-
Multiple alarm mode selection
-
Support temperature correction and support for power loss (the parameters of the sudden power failure are still valid
-
Application range is like home temperature control, farm, various cold storage, greenhouse, aquarium, etc
-
Display Type: Digital
-
Temperature sensor: NTC 10K
-
Senor length:1.0m
-
Temperature measuring range: -55 ° C ~ 120 ° C / -66°F~248°F
-
Resolution: 0.1 ° C
-
Accuracy:±1° C
-
Power supply: 110-220VAC 50/60Hz, 12V DC , 24V DC(Please choose power supply when ordering)
-
Power consumption: <3W
-
Storage temperature: -30 ° C ~ 75 ° C
-
Relative humidity: 20% ~ 85% (No condensate)
-
Relay contact capacity: 10A/240VAC; Heat 10A/240VAC
-
Normal mode: The red digital tube on the left shows the real-time temperature, the blue digital tube on the right shows the set temperature.
-
Setting mode: The red digital tube on the left displays the setting mode, the blue digital tube on the right displays the setting contents.
Specifications:
-
Be able to control temperature and humidity at the same time.
-
Be able to connect with refrigeration/ heating and humidifier/dehumidifier equipment at the same time.
-
Heating/Cooling function could be set separately for refrigeration and heating to protect temperature controller from violent change. Same as humidity Control.
-
Supporting Temp and Humidity Calibration
-
Dual Display Window,Be able to display measured temperature/humidity and set temp/humidity at the same time
Features:
-
Power Supply: 110-220VAC ± 10%, 50/60Hz or DC 12V
-
Temperature Control Range: 0°C~+110°C
-
Humidity Control Range: 0%RH~99.9%RH
-
Accuracy: +/-1°C 0.1% RH
-
Relay Capacity: 10A/240V AC
-
Integrated sensor: Sense temperature and humidity
-
Heating: Start temperature<Stop temperature
-
Cooling: Start temperature>Stop temperature
-
Humidification: Start humidity<Stop humidity
-
Dehumidification: Start humidity >Stop humidity
Set the start or stop temperature:
Long press UP 1 button for 3 seconds, ① display flashes, press UP 1 or DOWN 1 button to set the start temperature (20°C default)
Long press DOWN 1 button for 3 seconds ① the display flashes, press UP 1 or DOWN 1button to set the stop temperature (30°C default)
Set the start or stop humidity:
Long press UP 2 button for 3 seconds, ② display flashes, press UP 2 or DOWN 2 button to set the start humidity (40%RH default)
Long press DOWN 2 button for 3 seconds, ② the display flashes, press UP 2 or DOWN 2 button to set the stop humidity (60%RH default)
Reset:
Long press DOWN 1 and DOWN 2 button for 3 seconds to reset the controller.
Calibration method:
Long press UP 1 and DOWN 1 to calibrate the temperature, -10~10 °C
Long press UP 2 and DOWN 2 to calibrate the humidity
Package Content:
-
1 x STC-3028 temperature humidity controller
-
1 x temperature humidity sensor
