PowMr 3.2KW 2KW 1.5KW 1KW Hybrid Solar Inverter 12V 24V Battery to 230VAC Pure Sine Wave Output With MPPT 80A Solar Controller
15,073.80৳ – 45,336.20৳
| Color |
1.5KW 24V ,1KW 12V ,2KW 12V ,3.2KW 24V |
|---|---|
| Input Voltage |
No WI-FI ,With WI-FI |
| Output Voltage |
220-240V |
| Ships From |
CHINA ,GERMANY ,Mexico ,United States |
♦ Disclaimer: AliMarket একটি ক্রস বর্ডার শপিং সার্ভিস প্রোভাইডার। আমাদের মূল লক্ষ্য বর্ডার বাধা পেরিয়ে আপনাকে কাঙ্ক্ষিত পণ্য এনে দেওয়া। AliMarket এ প্রদর্শিত প্রোডাক্ট বিভিন্ন থার্ড পার্টি শপিং ওয়েবসাইট থেকে সংগৃহীত। অর্থাৎ AliMarket সরাসরি কোন পণ্যের সেলার বা ম্যানুফ্যাকচারার নয়। তাই AliMarket কোনো প্রাসঙ্গিক, জামানত বা যৌথ দায় নিতে বাধ্য নয়। তবে গ্রাহক স্বার্থ রক্ষার্থে শপিং ওয়েবসাইটের রিফান্ড পলিসি অনুসারে AliMarket বিফর এবং আফটার সেলস সার্ভিস দেয়।
- Hign-concerned Chemical: None
- is_customized: Yes
- Output Current: MPPT 80A
- Model Number: POW-HVM Hybrid Inverter
- Output Power: 1 – 200KW
- Size: 348X270X95mm
- Output Type: SINGLE
- Weight: 5.8kg
- Brand Name: PowMr
- Output Frequency: 50Hz/ 60Hz (Auto-detection)
- Is Smart Device: YES
- Origin: Mainland China
- Certification: CE
- Item: Hybrid solar inverter
- Product: hybrid solar inverter
- Description: photovoltaic hybrid inverter
- Charging: pure sine wave inverter
- Output voltage range: 220-240VAC
- PV Array MPPT Voltage Range: 30VDC-150VDC, 30VDC-400VDC
- Working efficiency: >95%
- Battery type: Lifepo4, Lithium, Flooded, Gel, Lead-acid Batteries
- Load type: Household appliances, farm tools, farm tools
- Equipment: Factory equipment, commercial load, industrial machinery
- Applicable area: Asia, Europe, Africa and North America (220-240VAC drivers)
PowMr 3.2KW 2KW 1.5KW 1KW Hybrid Solar Inverter 12V 24V Battery to 230VAC Pure Sine Wave Output With MPPT 80A Solar Controller
Introduction:
This is a multi-function inverter/charger, combining functions of inverter, solar charger, and battery charger to offer uninterruptible power support with portable size.Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
Features:
• Pure sine wave inverter
• Configurable input voltage range for home appliances and personal computers via LCD setting
• Configurable battery charging current based on applications via LCD setting
• Configurable AC/Solar Charger priority via LCD setting
• Compatible with mains voltage or generator power
• Auto restart while AC is recovering
• Overload/ Over temperature/ short circuit protection
• Smart battery charger design for optimized battery performance
• Cold start function
• WIFI/GPRS(Option)
• Can connect to lithium battery
Specification:
|
Picture |
|
|
|
|
|
INVERTER MODEL |
1KW 12V |
1.5KW 24V |
2KW 12V |
3.2KW 24V |
|
Rated Output Power |
1000VA/1000W |
1500VA/1500W |
2000VA/1600W |
3200VA/3000W |
|
Output Voltage Waveform |
Pure Sine Wave |
Pure Sine Wave |
||
|
Output Voltage Regulation |
230Vac士5% |
230Vac士5% |
||
|
Output Frequency |
50Hz/ 60Hz (Auto-detection) |
50Hz/ 60Hz (Auto-detection) |
||
|
Peak Efficiency |
94% |
94% |
||
|
Overload Protection |
3s@>150% load;5s@ 100%~150% load |
5s@ >150% Io ad; 10s@ 110% ~ 150% Io ad |
||
|
Surge Capacity |
2* rated power for 5 seconds |
2* rated power for 5 seconds |
||
|
Charging Algorithm |
3-Step |
3-Step |
||
|
AC Charging Current (Max) |
40Amp |
60Amp |
||
|
Max. PV Array Power |
600W |
1200W |
2000W |
3000W |
|
PV Array MPPT Voltage Range |
20~150Vdc |
30~150Vdc |
30~400Vdc |
30~400Vdc |
|
PV Array MPPT Voltage Range |
150Vdc |
400Vdc |
||
|
Max(AC+Solar)Charging current |
80Amp |
80Amp |
||
|
Safety Certification |
CE |
CE |
||
|
Operating Temperature Range |
-10°C to 50°C |
-10°C to 50°C |
||
|
Storage temperature |
-15°C- 60°C |
-15°C- 60°C |
||
|
Humidity |
5% to 95% Relative Humidity(Non-condensing) |
|||
|
Dimension |
286X240X91 |
357x273x95 |
||
